Rugged Computers

IDISPLAYS Rugged Computer series (RugSys) are designed and built to meet the most critical applications in the military and industrial area. The design complies to EMI /EMC MIL -461 standards. The compact rugged aluminium hosing meets MIL-810 environmental standards


The Systems are designed to allow easy up gradation to support the latest technology processors and displays without any change in the environmental characteristics.
Over the last 16 years, IDISPLAYS Rugged PC’s has been successfully implemented and used by various industrial and military projects in INDIA & Worldwide


Environmental Specification

  • Temperature : MIL-STD-810F (Method 501.4 / 502.4)
  • Humidity : MIL-STD-810F (Method 507.4)
  • Vibration : MIL-STD-810C (Method 514.2)
  • Shock : MIL-STD-810C (Method 516.2)
  • EMI/EMC : MIL-STD-461F Standards

A Family of rugged Computers ID-Rug-PC Series

  • Processor : Intel Core i7-5650U(2×2.20GHz)
  • Option: Celeron 3755U, i3-5010U, i5-5350U
  • Memory : Upto 8GB
  • Video : Intel HD Graphics
  • Storage : SSD up to 1TB
  • Interfaces : interfaces USB2.0 – 4, USB3.0 – 4, HDMI – 2, RS232/422/485 – 4, LAN 10/100/1000 – 5, microphone/audio (7+1) – 2
  • Size : 282x182x75mm
  • Power : 12-36VDC 40W external back up battery – optional
  • Operating Temperature : -40C +70C
  • Humidity/Rain/Dust : 98% at 35C, 60-107KPa / Rain – 5mm/min / Dust – 2g/m3 wind 0.5-1m/s
  • Vibration/Shock : Vibration – 5g at 5-500Hz / Multiple Shock – 15g 5-10ms
Model No ID-065 ID-104 ID-121 ID-150 ID-190 ID-210 ID-240
Screen Size 6.5 Inch 10.4 Inch 12.1 Inch 15 inch 19 inch 21 inch 24 inch
Resolution 1024 x768 1024 x768 1024 x768 1024x768
1600x1200
1280 x1024 1600 x1200 1600 x1200
Aspect ratio
4:3
Brightness
(Sunlight
readable
optional)
450 Nits 600 Nits 500 Nits 600 Nits 650 Nits 1200 Nits 1000 Nits
Contrast ratio 800:1 800:1
Backlight
LED WITH 100000 HRS MTBF
Colors
262K/16.7M
View angle
80/80/80/80 (Typ.)(CR≥10)
Environment
Operating Temperature: -10 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)
Mounting Type
Rack mount / Panel Mount / Console mount
